Laser cut is a process that uses a laser to cut different materials for both industrial and more artistic applications, such equally etching.

This article is 1 of a series of TWI frequently asked questions (FAQs).

Click here to run into our latest technical engineering science podcasts on YouTube.

How Does Laser Cutting Piece of work?

Laser cutting uses a high-power laser which is directed through optics and computer numerical control (CNC) to direct the beam or material. Typically, the process uses a motility control organisation to follow a CNC or G-lawmaking of the pattern that is to be cut onto the cloth. The focused laser beam burns, melts, vaporises or is blown away by a jet of gas to leave a high-quality surface finished edge.

The light amplification by stimulated emission of radiation beam is created by the stimulation of lasing materials through electrical discharges or lamps within a airtight container. The lasing cloth is amplified by being reflected internally via a partial mirror until its energy is plenty for information technology to escape equally a stream of coherent monochromatic light. This lite is focused at the work surface area by mirrors or fibre optics that direct the beam through a lens which intensifies information technology.

At its narrowest signal, a light amplification by stimulated emission of radiation beam is typically under 0.0125 inches (0.32 mm) in diameter, only kerf widths every bit pocket-sized as 0.004 inches (0.10mm) are possible depending on material thickness.

Where the laser cut process needs to start anywhere other than the edge of the material, a piercing process is used, whereby a high power pulsed laser makes a hole in the fabric, for instance taking 5-15 seconds to burn through a 0.5-inch-thick (13 mm) stainless steel sheet.

Types of Laser Cutting

This process can be broken downwards into three primary techniques - CO₂ laser (for cutting, boring, and engraving), and neodymium (Nd) and neodymium yttrium-aluminium-garnet (Nd:YAG), which are identical in style, with Nd being used for high free energy, low repetition dull and Nd:YAG used for very loftier-power boring and engraving.

All types of lasers tin be used for welding.

CO₂ lasers involve the passing of a electric current through a gas mix (DC-excited) or, more popularly these days, using the newer technique of radio frequency energy (RF-excited). The RF method has external electrodes and thereby avoids problems related to electrode erosion and plating of the electrode material on glassware and optics that tin can occur with DC, which uses an electrode inside the crenel.

Some other factor that can touch on laser performance is the type of gas flow. Common variants of CO₂ laser include fast axial flow, slow axial flow, transverse menses, and slab. Fast centric flow uses a mixture of carbon dioxide, helium and nitrogen circulated at a high velocity past a turbine or blower. Transverse flow lasers use a elementary blower to circulate the gas mix at a lower velocity, while slab or diffusion resonators use a static gas field which requires no pressurisation or glassware.

Different techniques are also used to cool the light amplification by stimulated emission of radiation generator and external eyes, depending on the system size and configuration. Waste matter heat can be transferred directly to the air, but a coolant is commonly used. H2o is a frequently used coolant, oft circulated through a heat transfer or chiller system.

Ane instance of h2o cooled laser processing is a laser microjet system, which couples a pulsed laser beam with a low-pressure level h2o jet to guide the beam in the same mode every bit an optical fibre. The h2o also offers the advantage of removing debris and cooling the fabric, while other advantages over 'dry' laser cut include high dicing speeds, parallel kerf, and omnidirectional cutting.

Fibre lasers are besides gaining popularity in the metal cutting industry. This technology uses a solid gain medium rather than a liquid or gas. The light amplification by stimulated emission of radiation is amplified in a glass fibre to produce a far smaller spot size than that achieved with CO_two techniques, making information technology ideal for cutting reflective metals.

Where is it Used?

This technology tin can be used for a variety of applications, including cutting and scribing metals such every bit aluminium, stainless steel, mild steel and titanium. Even so, the process can too be used for the industrial cutting of plastic, wood, ceramics, wax, fabrics, and paper.

Laser cut technologies are used across a range of industries, including aerospace and automotive applications also as for cutting in hazardous environments, such as with nuclear decommissioning.

Metal

Cut metal is one of the most common applications of light amplification by stimulated emission of radiation cutting and is used on materials including stainless and mild steel, tungsten, nickel, brass and aluminium. Lasers are ideal for cut metal as they provide clean cuts with a smooth cease.

Light amplification by stimulated emission of radiation cut metal can exist widely found for components and structural shapes including car bodies, mobile phone cases, engine frames or panel beams.

Wood

This cut procedure can be used with woods, with MDF and birch plywood among the almost common substances chosen as they can be manufactured in large sheets. The harder the woods, the greater the laser ability required, with dense hardwoods needing more than power than softer wood like balsa.

Wood is a favoured fabric equally it provides strength without the cost of metals however, on the downside, forest can warp or bend over time, especially if placed under high strain or used in a damp surround. Bated from cut, lasers are also frequently used to engrave forest, with CAD programs being used to create precise yet complex designs.

The Advantages

Laser cutting offers a number of advantages over other processes, such as reduced contamination and easier workholding. Precision can likewise see improvements with lasers as the beam does not habiliment down during the cutting process, while materials are as well less decumbent to warping with light amplification by stimulated emission of radiation cut. Lasers let for the cut of materials that may be difficult to cut using other methods.

Light amplification by stimulated emission of radiation processes likewise provide consistently high levels of precision and accuracy with fiddling room for human mistake, creating less wastage, lower energy use and subsequently lower costs.

Light amplification by stimulated emission of radiation cutting can be used to compose complex designs on smaller parts while still leaving metal free of burrs and with a clean cut. At that place is also less workpiece contamination with laser cut than with other processes.

The Disadvantages

While at that place are plenty of advantages, the process is besides synonymous with loftier power consumption. Furthermore, laser cut of plastics creates toxic fumes which need to exist ventilated – in itself an expensive task.

Effective laser cutting is likewise dependant on the thickness of the workpiece, the material being cut and the blazon of laser existence used. Without proper care the materials to be cut tin can exist burnt while some metals can discolour unless the correct laser intensity is used. While plasma cutting however allows for the cutting of thicker sheets than laser cutting, advances in light amplification by stimulated emission of radiation technology hateful that the gap is closing, although the machinery costs can still be prohibitive.

Finally, while beingness an automatic process, test runs and repairs require human involvement which leads to a risk of serious burns should an operator come into contact with the laser.
